You can download a deluxe SketchUp drawing of the Schoolbox, a project that was featured on the cover of the Autumn 2009 issue.

This file was made by Randall Wilkins, a set designer in the film industry who uses SketchUp in his job and in his woodworking hobby. This file is extremely cool. Here are some details.

Wilkins has added additional scenes (click on the tabs at the top of the file) that will create shop drawings for you in a variety of views, including some helpful section views. All the surfaces have a nice wood grain pattern on them. And the box’s lid is now a dynamic component , which means it will open and shut with a mouse click. Here’s how to do that:

In Sketchup, go to View/Tool Palettes/Dynamic Components, a new tool palette will open. Click on the little hand and then touch the box lid. It will open and close again on the next click.
